PIC16F886

28-Pin, FLASH-Based, 8-Bit, CMOS Microcontroller, SOP OR DIP, 50 nA Standby Current, Watchdog Timer Current

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.89~0.92 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.89~0.92

PartNumber:: PIC16F886

Brand:: Microchip Technology - Microchip | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. yoyo's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-09-21

From Other Seller

Part Number:PIC16F886
US $0.89 - 0.92
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The PIC16F886 is covered by this data sheet. It is a 28-Pin, Enhanced Flash-Based 8-Bit CMOS Microcontroller with nanoWatt Technology. The PIC16F886 is available in 28-pin PDIP, SOIC, SSOP and QFN packages.

Parametrics

PIC16F886 absolute maximum ratings: (1)Ambient temperature under bias: -40℃ to +125℃; (2)Storage temperature: -65℃ to +150℃; (3)Voltage on VDD with respect to VSS: -0.3V to +6.5V; (4)Voltage on MCLR with respect to Vss: -0.3V to +13.5V; (5)Voltage on all other pins with respect to VSS: -0.3V to (VDD + 0.3V); (6)Total power dissipation: 800 mW; (7)Maximum current out of VSS pin: 300 mA; (8)Maximum current into VDD pin: 250 mA; (9)Input clamp current, IIK (VI < 0 or VI > VDD): ± 20 mA; (10)Output clamp current, IOK (Vo < 0 or Vo >VDD): ± 20 mA; (11)Maximum output current sunk by any I/O pin: 25 mA; (12)Maximum output current sourced by any I/O pin: 25 mA; (13)Maximum current sunk by PORTA, PORTB and PORTE (combined): 200 mA; (14)Maximum current sourced by PORTA, PORTB and PORTE (combined): 200 mA; (15)Maximum current sunk by PORTC and PORTD (combined): 200 mA; (16)Maximum current sourced by PORTC and PORTD : 200 mA.

Features

PIC16F886 features: (1)Power-Saving Sleep mode; (2)Wide operating voltage range (2.0V-5.5V); (3)Industrial and Extended Temperature range; (4)Power-on Reset (POR); (5)Power-up Timer (PWRT) and Oscillator Start-up; (6)Timer (OST); (7)Brown-out Reset (BOR) with software control; (8)option; (9)Standby Current: 50 nA @ 2.0V, typical; (10)Operating Current: 11μA @ 32 kHz, 2.0V, typical; 220μA @ 4 MHz, 2.0V, typical; (11)Watchdog Timer Current: 1μA @ 2.0V, typical; (12)24/35 I/O pins with individual direction control.
