Product Summary
The PIC16F688-I is covered by this data sheet. It is a 14-Pin Flash-Based, 8-Bit CMOS Microcontroller with nanoWatt Technology. It is available in 14-pin PDIP, SOIC, TSSOP and QFN packages.
Parametrics
PIC16F688-I absolute maximum ratings: (1)Ambient temperature under bias: -40℃ to +125℃; (2)Storage temperature: -65℃ to +150℃; (3)Voltage on VDD with respect to VSS: -0.3V to +6.5V; (4)Voltage on MCLR with respect to Vss: -0.3V to +13.5V; (5)Voltage on all other pins with respect to VSS: -0.3V to (VDD + 0.3V); (6)Total power dissipation: 800 mW; (7)Maximum current out of VSS pin: 95 mA; (8)Maximum current into VDD pin: 95 mA; (9)Input clamp current, IIK (VI < 0 or VI > VDD): ± 20 mA; (10)Output clamp current, IOK (Vo < 0 or Vo >VDD): ± 20 mA; (11)Maximum output current sunk by any I/O pin: 25 mA; (12)Maximum output current sourced by any I/O pin: 25 mA; (13)Maximum current sunk by PORTA, PORTB and PORTE (combined): 90 mA; (14)Maximum current sourced by PORTA, PORTB and PORTE (combined): 90 mA.
Features
PIC16F688-I features: (1)Power-Saving Sleep mode; (2)Wide operating voltage range (2.0V-5.5V); (3)Industrial and Extended Temperature range; (4)Power-on Reset (POR); (5)Power-up Timer (PWRT) and Oscillator Start-up; (6)Timer (OST); (7)Brown-out Reset (BOR) with software control; (8)option; (9)Standby Current: 50 nA @ 2.0V, typical; (10)Operating Current: 11μA @ 32 kHz, 2.0V, typical; 220μA @ 4 MHz, 2.0V, typical; (11)Watchdog Timer Current: 1μA @ 2.0V, typical; (12)12 I/O pins with individual direction control.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 PIC16F688-I/ML |
Microchip Technology |
8-bit Microcontrollers (MCU) 7KB 256 RAM 12I/O |
Data Sheet |
|
|
||||||||||||
|
PIC16F688-I/P |
Microchip Technology |
8-bit Microcontrollers (MCU) 7KB 256 RAM 12 I/O |
Data Sheet |
|
|
||||||||||||
|
PIC16F688-I/ST |
Microchip Technology |
8-bit Microcontrollers (MCU) 7KB 256 RAM 12 I/O |
Data Sheet |
|
|
||||||||||||
|
PIC16F688-I/SL |
Microchip Technology |
8-bit Microcontrollers (MCU) 7KB 256 RAM 12 I/O |
Data Sheet |
|
|
||||||||||||
|
PIC16F688-I/STG |
Microchip Technology |
8-bit Microcontrollers (MCU) 7KB 256 RAM 12 I/O Lead Free Package |
Data Sheet |
Negotiable |
|
||||||||||||
